Customizable Medium-Sized Industrial Bag Filter Designed for High Air Processing Volume

Name: Customizable MediumSized Industrial Bag Filter Designed for High Air Processing Volume
Brand: CHITY
Price: 1 USD

Quality Customizable Medium-Sized Industrial Bag Filter Designed for High Air Processing Volume for sale

Applicable Industries : Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Construction works , Energy & Mining, Food & Beverage Shops, Other

Showroom Location : None

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2024

Warranty of core components : 1 Year

Core Components : Pump, Filter bag, Pump

Condition : New

Place of Origin : Hebei, China, Hebei, China

Brand Name : CHITY

Dimension(L*W*H) : Design according to requirements

Weight : 1000 kg

Warranty : 1 Year

Product name : Industrial Dust Collector

Application : Energy & Mining And so on

Graphic Customization : Accepted

Dust Collection Type : Pulse Dust Collector

Processing air volume : 230-9216m ³/ H

Filter Area : 4.8 - 1480 m²

After-sales Service Provided : Engineers available to service machinery overseas

Price : $1,250.00/pieces 1-9 pieces

MOQ : 1 piece

Contact Now

Customizable Medium-Sized Industrial Bag Filter Designed for High Air Processing Volume

Product Parameters

The baghouse dust collector is a filter-type dust removal equipment based on the principle of filtration, which uses the fiber or inorganic fiber filter cloth of the agricultural production system to filter out the dust in the gas. Dust removal process: the dust-containing gas enters the middle box from the air inlet, enters the bag from the outside of the filter bag, the dust is blocked on the surface outside the filter bag, the purified air enters the bag, and then enters the upper box from the upper part of the bag, and then is discharged by the exhaust pipe.

Model	Filter area/㎡	Processing air volume m ³/ H	Number of pulse valves/unit	Length and width dimensions/mm	Box height/mm	Ash hopper height/mm	Processing efficiency%	Resistance/Pa	Weight/kg
MC-12	9.6	461	3	680x855	2400	650	99.6%	1200	480
MC-16	12.8	615	4	855x855	2400	650	99.6%	1200	540
MC-20	16	768	4	855x1025	2400	720	99.6%	1200	610
MC-24	19.2	922	4	855x1200	2400	870	99.6%	1200	695
MC-36	28.8	1382	6	1200x1200	2400	870	99.6%	1200	845
MC-48	38.4	1843	8	1600x1200	2400	1200	99.6%	1200	1070
MC-64	51.2	2458	8	1600x1600	2400	1200	99.6%	1200	1265
MC-80	64	3072	10	1960x1600	2400	1500	99.6%	1200	1510
MC-96	76.8	3686	12	2300x1600	2400	1820	99.6%	1200	1760
MC-120	96	4608	12	2300x1960	2400	1820	99.6%	1200	1990
MC-160	128	6144	16	3100x1960	2500	1500	99.6%	1200	2400
MC-180	144	6912	18	3400x1960	2500	1500	99.6%	1200	2560
MC-200	160	7680	20	3800x1960	2500	1500	99.6%	1200	2790
MC-240	192	9216	24	4500x1960	2500	1650	99.6%	1200	3250

Products Description

Company Profile

CUSTOMER VISIT

Partners

We have partners all over the world. Welcome to become our new partner.

OUR SERVICE ?

We have strong technology term and installation personnel, we are able to design and manufacture dust collector with different capacity.

FAQ

1.The quality

Welcome to our factory and check the quality of product.And we will send you the video and pictures before shipment
after you order.

2. how can we guarantee quality?

Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?

Dust Collector, Conveying Equipment, Filter Bag, Desulfurization Equipment, De-Nox Equipment

4. Why do you want to purchase from us instead of other suppliers?

1. Quick quotation within 24 hours upon inquiry. 2. High quality and cost-effectiveness make it your best choice 3. A professional R&D team designs dust removal technology based on the specific situation of the dust collector. 4. After sales service, solving all troubles

5.Equipment warranty

A.Equipment with 12 months warranty, can be extended to 24 months as request.
